High Speed Fold Up Doors are designed for large external openings, offering quick access while withstanding high wind pressures. Built for durability and efficiency, these doors feature a strong folding system and reinforced curtain for added resistance, making them ideal for warehouses, factories, and distribution centres.
Our High Speed Fold Up Doors are engineered to provide maximum efficiency and strength for external applications. With a robust folding system, they incorporate steel reinforcement tubes within the curtain, ensuring exceptional resistance to wind and negative pressure.
These high performance doors are perfect for large openings, such as warehouses, factories, distribution centres, and process plants. The high-quality construction offers fast opening speeds, strong wind resistance, and reliable safety features, including wireless safety bottom edges and photo-cell technology.
The curtains are made from 100% high-strength polyester fabric, coated with PVC on both sides, and reinforced with horizontal strengtheners to protect against draughts and strong winds. 2x rows of vision panels is supplied as standard, with the option to add more for greater visibility.
The high speed fold up door is the ideal solution for medium/large sized bays, especially where high wind resistance is a must.
Standard supplied accessories – Safety Light Grid: Ensures maximum safety for through traffic, and personnel, avoiding completely direct contact with the curtain.
| Application(s) | Commercial buildings, External, Food production facilities, Garages and Workshops, Hospitals and healthcare facilities, Industrial units and warehouses, Storage Units, Transport Depots |
|---|---|
| Curtain material(s) | High strength polyester fabric |
| Curtain Colour(s) | |
| Leaf & frame colour(s) | |
| Max. area | 20m² |
| Opening speed | Up to 1.2m/sec |
| Wind resistance (km/h) [size dependent] | Wind Load: Maximum class 2 EN 12424. Class 3 available as an optional extra. |
Endurance
Use: Suitable for intensive and continuous use applications.
Solidity: The frame / canopy is made from 2mm galvanised steel, making the structure very strong, sturdy and self supporting – with no welded parts.
Lifetime: Tested in working conditions to over 1.5 million cycles, with excellent results.
Resistance: Wind load and differences in pressure up to Class 2 (EN12424) when tested in the fully closed position. Operational wind loads will vary depending on door size & installation accuracy. Upgrade to Class 3 optional.
Details
Maximum Dimensions: 20,000 x 12,000 mm WxH – Special versions are available up to 30,000mm x 25,000mm (gigabelt)
Frame/Guides: 2mm thick galvanised steel. Stainless steel AISI 304 or 316 available as an optional extra (powder coating is available as an optional extra)
Roller: Galvanised steel
Motor: Three phase, self braking
Curtain: Polyestic fabric, coated with coloured PVC (to choose colours see the chart) 900 g/m2. Insulated as an optional extra. (1300g/m2 insulated material available on request)
Vision: Rectangular vision panels with rounded corners.
Override: By cranks, counterweights optional
Standard: Compliant with EN 13241
Wind Load: Maximum class 2 EN 12424. Class 3 available as an optional extra.
Temperatures: From 0°C up to + 70°C
Our High Speed Fold Up Doors offer various optional upgrades to meet diverse operational needs and site conditions.
A&C Maintenance combines decades of expertise with a commitment to quality and safety. Our doors are designed, installed, and maintained with precision engineering and advanced technology to deliver exceptional performance in demanding environments.
When you select A&C Maintenance, you are opting for a reliable partner that delivers not only exceptional products but also thorough support and service.
Our high-speed, foldable industrial doors come equipped with various safety features, including a wireless safety bottom edge and photo cell technology located 500mm above the ground. These systems identify obstacles to prevent unintended closures, thus safeguarding both personnel and equipment. Furthermore, an auto-timed return function and a manual emergency operation via a crank handle at floor level offer added reassurance during emergencies.
These doors are perfect for large openings in environments exposed to high wind pressures and demanding external conditions. Typical applications include warehouses, factories, distribution centres, and process plants where durability, operational speed, and safety are paramount.
High speed fold up doors are external doors designed for rapid operation using a folding mechanism. Unlike traditional roller shutters, these doors are engineered to fold vertically in sections, ensuring a compact headbox and a strong structure reinforced with steel tubes. They are ideal for applications where fast access and high wind resistance are critical.
