Insulated Roller Shutters

A range of vertical insulated roller shutters is available with manual or electric operation. When the shutter is open, it coils up neatly above the opening and does not encroach upon or cover the roof area behind the door. These shutters are designed for warehouses, industrial units, garages, workshops, schools, hospitals, bus depots, agricultural buildings, and more.

Advantages

Aesthetic design
Auto timed return
Choice of most RAL Colours
Customisable Upgrades Available
Durability
High Security

Safety Features

Manual Override
Safety Brake
Safety Edge
Safety photo cells
Wear-resistant plastic strips in side guides
Wireless safety bottom edge

Interested in Ordering?

Suited to Agriculture / Commercial / Food Industry / Health / Industrial / Retail sector applications.

Check the tabs below for more information.

Description

Insulated Roller Shutters for Efficient Protection

The Insulated Roller Shutter is a versatile and high-performance solution for a wide range of applications, providing both insulation and security. Perfect for use in commercial, industrial, and agricultural environments, this shutter ensures that your property is well-protected while benefiting from energy efficiency due to its insulation properties. The shutter coils up neatly above the opening when not in use, keeping the roof area clear and free from obstruction.

Constructed from a 0.7mm galvanised steel curtain, the shutter is designed for lasting strength. The curtain features interlocking laths that include insulation to achieve the required U-value. For added protection, the bottom of the curtain is fitted with an extrusion and a rubber strip. The roller assembly consists of a mild steel tube mounted on bright steel shafts, ensuring smooth operation. Cold-rolled galvanised mild steel side guides provide the necessary structure to secure the shutter to the opening, with wear-resistant plastic strips added for durability.

Additional information

Application(s)

Commercial buildings, External, Food production facilities, Garages and Workshops, Industrial units and warehouses, Storage Units, Transport Depots

Curtain material(s)

Galvanised steel

Frame material(s)

Galvanised steel

Finish

Plastisol Finish, Polyester powder coat

Lath height

100mm

Max. area

20m²

Mode of operation

Electric

Seal options

Head seal, Twin-pile guide seal

Curtain Colour(s)
Leaf & frame colour(s)

Standard Specification

Mode of Operation
Manual operation is delivered via a hand chain mechanism, supported by reduction gearing and mechanical springs housed within the barrel, allowing smooth and controlled lifting. Alternatively, electric operation is available using a reliable 3-phase 415v Safedrive motor with an integRAL safety brake or a single-phase 240v tube motor, both offering efficient and consistent performance.

Curtain
The curtain is made from 0.7mm galvanised steel with a durable twin-ribbed face. It features interlocking laths, each filled with insulation to provide thermal efficiency and increased strength. At the base of the curtain, an extrusion and rubber strip are fitted to help cushion closure and seal the bottom edge effectively.

Roller Assembly
Constructed from mild steel tube, the roller assembly is mounted on bright steel shafts which rotate smoothly within ball races. This setup ensures reliable performance and reduces operational friction, prolonging the life of the system.

Side Guides
Side guides are formed from cold-rolled galvanised mild steel, shaped into a channel section that supports and directs the curtain. To reduce wear and minimise noise during operation, wear-resistant plastic strips are fitted to the toes of the guides.

Optional Extras

Colour Finish

Polyester powder coat to standard BS or RAL colours (subject to availability).

Seals

  • Twin Pile Guide Seal
  • 100 – 200mm Head Seal
  • Threshold Seal

Canopies & Closures:

  • Hood Cover
  • Fascia
  • Soffit
  • Jamb Flashing Closure

Personnel Doors

  • Steel Hinged Door (With fixed infill panel)

Security Options & Upgrades:

  • Chain Keep
  • Ground Lock
  • Keyswitch Locking Box
  • Anti-Ram Raid Posts

Door Protection

  • Steel Protection Bollards (Powder coated yellow and supplied with yellow & black hazard tape as standard).
  • Steel Jamb Protection

Safety Options

  • Photo Cells
  • Safety Bottom Edge
  • Ground Lock & Bullet Lock Interlock

Electric Operation Upgrades

  • Lockable Push Button Station
  • Rocker Switch
  • Key Switch
  • Radio Transmitters
  • Motion Detectors
  • Induction Loops
  • Photo Cells
  • Group Control

Resources

Frequently Asked Questions

Here are some answers to questions we are commonly asked about our Insulated Roller Shutters:

Industrial insulated roller shutter doors are specifically engineered to withstand the demands of continuous use in various industrial settings. These doors are constructed using high-quality materials that provide excellent insulation properties, helping to regulate internal temperatures and reduce energy costs.

Regular maintenance checks, including lubrication of moving parts and prompt repairs, are essential for ensuring the longevity and efficient operation of these doors. By taking proactive steps to care for industrial insulated roller shutter doors, businesses can maximise their investment and ensure a safe and secure working environment for years to come.

Insulated roller shutter products offer a range of benefits, including improved thermal efficiency, reduced energy expenses, enhanced security, and exceptional durability. These doors are well-suited for environments where maintaining a consistent temperature is essential, such as warehouses, industrial facilities, and commercial properties. By utilising high-quality materials and innovative design, insulated roller shutters provide a reliable and long-lasting solution for controlling temperature and enhancing security.

Insulated industrial roller shutter doors feature an extra layer of insulation within the slats, offering superior thermal control for commercial and industrial buildings. This added insulation aids in regulating the internal temperature, minimising heat loss during colder months and preventing heat gain in warmer months.

The enhanced energy efficiency of these doors not only helps lower heating and cooling costs but also creates a more comfortable working environment for employees. Ideal for warehouses, factories, and facilities where temperature control is essential, insulated roller shutter doors provide a practical solution for British businesses aiming to improve energy efficiency and reduce operating costs.

Insulated roller shutter doors consist of interlocking slats typically made from insulating materials like aluminium or steel. These doors offer numerous advantages, including enhanced thermal insulation that keeps buildings warmer in the winter and cooler in the summer, which helps reduce energy costs.

Furthermore, insulated roller shutter doors improve security levels, making them a favoured option for industrial, commercial, and residential properties. Overall, these doors represent a worthwhile investment for those seeking to enhance the efficiency and security of their buildings.
